SP10 Spirometer is a hand-held piece of equipment used to check the lung condition. It uses infrared mode to take relevant measurements, it is used to perform routine tests in hospitals, clinics, family medicine. Technical Specifications - Display Mode: 1.8'' color LCD - Screen Resolution: 160x128 - Volume Range: 0 ~ 10L - Volume Accuracy: ± 3% or 0.05L (whichever is greater) - Flow Range: 1 L / S ~ 16L / S - Flow Accuracy: ± 10% or ± 0.3L / s (whichever is greater) - Working Current: 60 mA - Power Supply: DC3.7V Rechargeable Lithium Battery Performance - Forced Vital Capacity (FVC), Forced Expiratory Volume in 1 Second (FEV1), FEV1 and FVC (FEV1%) ratio, Peak Current Rate (PEF), 25% of FVC flow (FEF25), 75% of FVC flow (FEF75) and the flow average of 25% and 75% of FVC (FEF2575) can be measured. In addition, the condition of the tested person can be shown with the ratio of the measured value and the estimated value. - Flow rate-volume table, volume-time table screen - Data memory deletion, loading and analysis - Trend table screen. - Scaling (Calibration) - Warning message when volume or flow is out of limits - Automatic shutdown feature when there is no operation within 1 minute Accessory List 1 pc USB Cable 1 pc Power Supply Physical Features Dimensions: 97 x 89 x 36 mm Weight: 150 g
